RFCOM-1008 AI Intelligent Controller

The RFCOM-1008 is an edge AI controller based on NVIDIA Jetson Orin Nano. It offers 20/40 TOPS configurations, a 6-core ARM Cortex-A78AE CPU, Ampere GPU, 4/8 GB onboard memory, NVMe expansion, and 9–36 VDC input for industrial edge applications.

Pricing, availability, certification and compatibility are confirmed during quotation.

Request a quote →

Product advantages

Designed for practical deployment.

Source-grounded

Product details are retained from the authorized source package.

Fit review

Share your requirements and our team will validate the configuration.

Commercial clarity

Lead time, warranty and final terms are confirmed before order.

Technical specifications

hardware_configurationAI performance | 20TOPS (S001), 40TOPS (S002)

cpu512*Cores NVIDIA Ampere architecture GPU with 16*Tensor Cores(S001) 1024*Cores NVIDIA Ampere architecture GPU with 32*Tensor Cores(S002)

specificationOn-board 4GB 64-bit LPDDR5 34GB/s (S001) / 8GB 128-bit LPDDR5 68GB/s (S002)

extended_interface1*M.2 3052 B-Key, with SIM card slot, supporting 4G LTE or 5G NR wireless function module 1*M.2 2280 M-Key, supporting NVMe high-speed memory card 1*Mini PCIe expansion slot

video_codecVideo coding 1080p30 supported by 1-2 CPU cores Video decoding H.265: 1*4K60 | 2*4K30 | 4*4K30 | 5*1080p60 | 11*1080p30;

audioRealtek ALC5640 audio, supporting stereo channel output

ethernetSupports 2*LAN 10/100/1000Mbps (default support for 2 ordinary Gigabit networks, 2 POE channels are optional)

store1*M.2 2280 M-Key, supporting NVMe ultra-high-speed solid-state storage; 1*Micro SD card

camera_interfaceSupports 2*4 lane Mipi (22 pins) by default, and optionally supports 4*GMSL interface

dio4-bit 2.5KV optically isolated DI (TTL signal), 4-bit 2.5KV optically isolated DO (TTL signal); 2*2.5KV optically isolated RS232 and RS485/422

i_o_interfaceSupports 2*RJ45 (with 2*POE optional); 1*HDMI; 2*USB3.2(Gen2 10Gbps,TypeA); 2*USB2.0 (Type A); 1*Line out; 1*Iso.RS232+1*Iso.RS485/422(2*5pin Phoenix terminal); 2*Iso.CAN (1 DB9, where one isolation is optional); 1*8-bit Iso.DIO (2* 6-pin Phoenix terminal); 1*SIM card slot; 1*Mico SD card slot; 4*ANT;

indicator_lightIndicator light | 1*Power LED(on the Power button), 1* operation light

switchControl switch | 1* Power key w/LED, 1*RST key; 1*REV button;

power_supplyPower Supply requirements | DC 9~36V wide voltage DC input, 3-pin 3.81mm pitch Phoenix socket, overvoltage and overcurrent reverse connection protection; TDP: TBD (Jetson NX Orin 8GB); DC 12V output maximum 3A, 4-pin 3.5mm pitch Phoenix socket

operating_systemOperating system | Linux Ubuntu 18.04 and 20.04 with JetPack

mechanical_parametersConstruction of | Fanless heat dissipation housing, SGCC box

color_tdGraphite black + Granite Gray

size(L*W*H)：Main box ：190*145*68mm

environmentOperating temperature | -20℃ to 60℃ (air flow)

storage_temperature_storage_humidity-40°C~85°C/ 10~90%@40°C, No condensation

vibration5grms/5~500Hz/ Random/Working state (SSD); 1grms/5~500Hz/ Random/Working State (HDD)

impact50g peak acceleration (sustained for 11ms)(SSD); 20g peak acceleration (for 11ms)(HDD)

emc_certificationCE/FCC Class A

modelRFCOM-1008 AI Intelligent Controller
