RFCOM-5108 Embedded Industrial Control Computer

PORTOWER product

RFCOM-5108 Embedded Industrial Control Computer

The RFCOM-5108 is an embedded industrial computer for automation control, machine vision, and edge computing. Its COMLAC modular design supports multiple computing platforms and configurable carrier and industry expansion boards. Cloudnine lists an Intel Celeron J6412 configuration, fanless operation, and industrial I/O; confirm build details when quoting.

Pricing, availability, certification and compatibility are confirmed during quotation.

Request a quote →

Product advantages

Designed for practical deployment.

Source-grounded

Product details are retained from the authorized source package.

Fit review

Share your requirements and our team will validate the configuration.

Commercial clarity

Lead time, warranty and final terms are confirmed before order.

Technical specifications

hardware_configurationCPU | Intel® Celeron J6412, 2.0~2.6GHz, 4 cores /4 threads, 1.5MB L2 cache

tdp10W

biosAMI UEFI 256Mb

memory1 x SO-DIMM DDR4-3200MHz (maximum support 32GB)

storage1 x M.2 2242

usb3 x USB3.1

com1 x RS232, 1 x RS485

ethernet_td3 x Intel Gigabit Ethernet port

dpThe maximum resolution is 4096 x 2160 @60Hz

hdmiThe maximum resolution is 3840 x 2160 @60Hz

extension_interface1 x full-size miniPCIe card slot with SIM card slot

do1 x Custom LED light

watchdogLevel 1 to 255 programmable Settings

operating_systemMicrosoft Windows | Windows 10

linuxUbuntu

power_supplyInput voltage | DC12-24V ± 10%, overcurrent, overvoltage and reverse connection protection

power_consumptionMaximum power consumption 45W

mechanical_parametersStructure | Sheet metal structure, fanless design, supports wall-mounted installation or DIN-Rail rail installation

size(L)138mm x (W)102mm x (H)48mm

net_weight1.06Kg

environmentWorking temperature | -20ºC ~ 60ºC (Use SSD)

storage_temperature-40ºC ~ 80ºC (Use SSD)

relative_humidity5-95% (Non-coagulated)

vibrationUse SSD: 5~500Hz, 1.5Grms, in compliance with IEC60068-2-64

impactUses SSD: 20G(duration 11ms, half sine wave), in compliance with IEC60068-2-27

emcCE/FCC Class B

modelRFCOM-5108 Embedded Industrial Control Computer

Applications

Tell us about the environment.

Campus, data-center, industrial, edge and project deployments can be scoped through the RFQ workflow.

Documents

Product documents and support

Datasheets, lifecycle information and software links are provided where the source package includes them.
